KEBIDU Handsfree Mic Recording Bluetooth MP3 Decoder Board DC 5V 12V LED Wireless Audio Decoding Module Support USB U Disk TF Card AUX FM Radio MP3 WMA With Remote Control

Feature:

• Support signal switch directly. Support USB, TF

• Support Bluetooth (Bluetooth3.0 EDR) (after been paired with mobile phones can realize wireless music play)

• Support USB / TF / Bluetooth/FM / LINE switch. MP3 / WMA, WAV lossless music decoding chip.

• Support USB / TF card switch, PREV, NEXT, fast forward, fast rewind, volume, EQ, play/pause, stop, single repeat, mute, shutdown, and direct election.

• Support Bluetooth PREV, NEXT, volume, EQ, play/pause, mute, turn it off.

• Support FAT16, FAT32 file system. Support for MP1 Layer3, MP2 Layer3, MP3 Layer3 version of the song.Support 32-320 KBPS MP3 songs.

• Support power-off memory function: memory play songs and volume before power off.

Note:

Non-smart phones (android) have to enter the password - 0000

Decoding board play mode instruction:

Decoding board in the absence of memory card or U disk,boot default to //'//'audio input//'//' mode,the screen display LINE

Press //'//'MODE//'//' key on the panel or the remote control switch to bluetooth MODE,the screen shows //'//'BLUE//'//',can open bluetooth search contion at this time

Press //'//'MODE//'//' key on the panel or the remote control switch to radio MODE,the screen display FM radio frequency,long press //'//'PLAY//'//' button automatic searching channel

Press //'//'MODE//'//' key on the panel or the remote control switch to the U disk or memory card //'//'play MODE//'//',the screen displays the time schedule of the song

The remote control instruction:

1. POWER: STANDBY button cannot switch.

2. MODE: TF card and U disk: switching sequence for USB→TF→Bluetooth→FM→AUX;

Only U disk: switching sequence for USB→Bluetooth→FM→AUX;

Only the TF card: switching sequence for TF→Bluetooth→FM→AUX;

There is no USB and TF card: switching sequence for FM→AUX→Bluetooth.

3. PREV: In USB/TF / Bluetooth MODE, short press for PREV;

In the USB / SD MODE, long press for fast rewind; In FM MODE, short press for last channel, long press for scan search last channel.

NEXT: In USB / TF/Bluetooth MODE,short press for NEXT;

In USB / TF MODE, long press for fast forward;

In FM MODE, short press for next channel, long press for scan searches the next channel.

4. VOL + : short / long press for music. VOL -: short/long press for music.

5. REP: In USB / TF MODE, it is the switch key between single repeat and whole cycle when play music, boot for all cycle.

6. STOP: In the USB / TF MODE, short press to STOP the music play.

7. MUTE: MUTE, press for MUTE, press again for relief (also can relieve by VOL- /VOL+).

8. EQ: Acoustic field MODE. The NORMAL→BAS→POP→ROC→JAZZ→CLA→CUT→NORMAL

9. PLAY/PAUSE: In USB/SD/Bluetooth MODE for PLAY / PAUSE; In the FM MODE, long press for searching all channels and save.

Specification:

Installation pitch: 92 mm wide

Installation hole: 83 x 20 x 38 mm

Overall dimensions: 107 x 25 x 38 mm

(W x H x D)

Input voltage: 5-12V

Package included:

1 x BluetoothDecoder Board

1 x Remote control (without Battery)

2 x Cables

Note: This item with bubble bag packaging, without a retail box, but please rest assured that we will pack it well before shipping!
