XTUGA RW2080 UHF Wireless In Ear Monitor System Whole Metal Designed SR2050 Type 2 Channel Transmitter With 4 Bodypack Receiver Professional Used for DJ Concert Stage Performance Music Monitoring

RW2080 UHF Live Sound Wireless In-Ear Monitor System

(2 Channel 4 Receivers)

Description:

WHOLE METAL UHF WIRELESS In Ear Monitor SYSTEM

This system comply with new FCC frequency rules.

There are total 3 different frequency range for this in-ear monitor system:

A. 572Mhz to 603Mhz

B. 550Mhz to 580Mhz

C. 902Mhz to 928Mhz

Twin transmitter Monitoring, Effective distance 100 Meter

2 channel Professional Wireless In Ear Monitor System for Stage Performance, Wireless Microphone Monitoring System with corner brace. This is an excellent dual channel in-ear monitor system. Can be use in stage, singing, speech, church, Simultaneous interpretation, tour guider....etc.

Feature:

LCD display shows clear working status

Low battery remind of bodypack receivers

2 power switch control

Have a mout in the both side of the mechine, easy to setup.

Strong signal, UHF frequency

Digital tone key locking technology to avoid possible interference.

40 preset channels separately by 4 groups, can be adjustable

Effective Distance: 100 Meter

Audio output: mono

Specification:

Transmitter:

Case specification: standard 1U Case material: metal panel Oscillation mode: PLL synthesized Frequency stability: ±0.005% Frequency range: UHF572-603.5MHz Frequency interval: 32MHz Preset Channel: 40 channel separately set 4 groups Operate mode: manual adjust Max Deviation: ±48KHz Frequency response: 50Hz~15KHz±3dB Transmit output power: 100mW(50Ω) Harmonic radiation: AF input: XLR, φ6.35mm jack Earphone output: φ6.35mm stereophonic socket Earphone load impedance: ≥16Ω Current consumption: DC 12V/250mA Antenna socket: TNC socket(50Ω)

Receiver:

Oscillation mode: PLL synthesized Frequency stability: ±0.005% Frequency range: UHF572-603.5MHz Frequency interval: 32MHz Preset Channel: 40 channel separately set 4 groups Operate mode: manual adjust Receiving mode: single tuning Sensitivity: deviation 25KHz, with connecting 7dBuV, S/N>78dB Max Deviation: ±48KHz Comprehensive S/N ratio: >94dB(1KHz-A) Comprehensive T.H.D: Frequency response: 80Hz~15KHz±3dB output power(32Ω): 2X35mW@1KHz Earphone load impedance: ≥16Ω Output socket: φ3.5mm stereo earphone socket Volume output adjusts: adjust when using Power box: batteries AA X2 Current drain: 3V/120mA(Under the median degrees of the volume control) Antenna: fixed 1/2λ

How to use:

Package Include(Whole system):

Transmitter × 1

Bodypack Receiver × 4

Antenna × 2

Earphone × 4

Cable Line × 4

Power Adapter × 1

User Manual × 1

Application:
