Ready stock 3/4//5/6/7/8/10mm Rigid Flange Coupling Motor Guide Shaft Coupler Motor Connector

Flange coupling is a special coupling that can fix a shaft to a flat surface and can easily install other accessories on the shaft. Large quantity, better price. The product is divided into two sizes according to the appearancepecification:Aluminum alloy is light, the top screw is 90 degrees design; 45# steel hardness is high, the top screw is 180 degrees design. If you want to aluminum coupler ,please buy Aluminum CouplingMaterial: 45# steel,hardened by heat treatment, and then electroplatedInner Diameter:3mm,3.17mm,4mm,5mm,6mm,6.35mmCylindrical Diameter: 10mm; Cylinder Height: 10mm; Overall Height: 12mm; Fixed Hole Screw:M3Fixed Hole Distance:16mmInner Diameter:7mm,8mm,10mm,11mm,12mmCylindrical Diameter: 16mm; Cylinder Height: 10mm; Overall Height: 13mm; Fixed Hole Screw:M4Fixed Hole Distance:26mm(11mm/12mm/14mm);24mm(others)Inner Diameter:14mmCylindrical Diameter: 18mm; Cylinder Height: 10mm; Overall Height: 13mm; Fixed Hole Screw:M4Fixed Hole Distance:26mmPackage Included:Coupler x 1Allen Key x 1Screw x 2
