JING 18/21V Battery Charging Protection Board Protection Circuit Li-Ion Circuit Board Module Module 20A Lithium Battery Pack Protection Power Tools

Overcharge Protection Delay:1S Length*Width:46x40mm Current:8-20A Operating Temperature: -55°-120° RH≤75% Store Temperature: -55°-175° RH≤75%Working State:25uA (25°) Charge Voltage:25V The protection board is for 5 series Li-ion batteries, mainly used for electric power tools. It uses special IC for 5S lithium batteries as processor to detect real-time voltage, charge and discharge current and ambient temperature of each battery. Stable various protective functions for charging and discharging, such as overcharge protection, over-discharge protection and short circuit protection. Low power consumption,the working current is about 25uA and quiescent current is about 6uA. Choosing the correct protection board and applying it appropriately is to your batteries.

Package Listing: 1Pc

Attention: The product color and chip layout may change due to different batches, but it does not affect the use of the product.
